CE Certificated, FDA registered

Specifications:
1. Working mode: Non-mydriatic color, Mydriatic FFA
2. Eye position aid: Alignment dots
3. Observing: Monitor + Anterior LCD
4. Resolution: 12M Max.
5. B/W resolution: 752*582
6. Field of view: 45 degree
7. Patient dioptor range: -10D to +10D
8. Working distance: F-B 40mm, L-R 120mm, U-D 80mm
9. Horizontal tilting: ±30o
10. Chin rest distance: 70mm
11. Electric-table distance: 200mm
12. Fixation: External LED + Internal target
13. Light source: IR + LED +FLASH

Electrical:
1. Power supply: AC 100V/220V 50HZ
2. Working temperature: -5o, -40o
3. Working humidity: 0% ~ 85%

Physical:
1. Dimension: 350*550*600mm
2. Weight: 50KGS

Software:
1. Image post processing: brightness, contrast, gamma, color, smooth, sharp etc.
2. Focus processing: measuring, marking, patching up etc.
3. Documents management: record, search, sort, report etc.
