Microscope type: |
Galilean system |
|
Magnification changer: |
3 steps Revolving Drum |
|
Total magnification: |
10X,16X,25X |
|
Eyepieces: |
12.5X |
|
Ocular Field: |
Ø18mm |
|
Inter pupillary distance: |
52mm～78mm |
|
Diopter adjustment: |
+6D to -6D |
|
Object image field in mm: |
Ø22(10X ), Ø13.5(16X),Ø8.5(25X) |
|
Slit illumination |
|
|
Slit image width: |
0～14mm continuous |
|
Slit image length: |
1～14mm continuous |
|
Light source: |
6v/20w halogen incandescent light bulb or 12V/10W LED light bulb |
|
Slit image radial range: |
0～180° |
|
Filters: |
Heat aborption,redfree(green),cobalt blue |
|
Illumination fields Ø in mm: |
0.2/1/2/3/5/10/14/1~14mm continuous |
|
Illumination intensity: |
≥50KLX |
|
Instument base |
|
Operation: |
Single handed 3-dimensional operation of the joystick |
|
Range of adjustment: |
90mm(longitudinal),100mm(lateral),30mm(vertical),15(fine) |
|
Chin-rest |
|
Fixation: |
Red led |
|
Vertical adjustment: |
80mm |
|
Power Supply |
|
Input voltage: |
220v/110v ±10% |
|
Input frequency: |
50Hz/60Hz |
|
Output power: |
Halogen bulb--30VA(max),LED bulb--15VA(max) |
|
Output voltage: |
Light source Halogen bulb--6V continuous,LED bulb--12V continuous.fixation 3V |
|
Ambient conditions Working |
|
Temperature: |
+5°C～+40°C |
|
Relative humidity: |
≤80% |
|
Air pressure: |
800hPa~1060hPa |
|
Storage |
|
Temperature: |
-40°C～+55°C |
|
Relative humidity: |
≤93% |
|
Air pressure: |
700hPa~1060hPa |
|
Transportation |
|
Temperature: |
-40°C～+55°C |
|
Relative humidity: |
≤93% |
|
Air pressure: &nb,sp;,;,; |
700hPa~1060hPa |
|
Packaging |
|
Carton: |
740mm X 450mm X 500mm |
|
Gross weight: |
22Kg(without electrical desktop and options) |
|
Net weight: |
17Kg(without electrical desktop and options) |
