CE Certificated, FDA registered
Description:
ZOOM magnification system, 4X～21X continuous adjustment.
Germany optical lens which provides sharp image and even filed.
Cold light source fiber illumination does no harm to tissues.
Covenient operation benefits from unique lifting turn-off.
Applicable in Stomatology, Gynecology, Hand surgery and ENT
Specification:
|
Eyepiece Magnification |
12.5×/16B |
|
Objective Lens |
f=250 |
|
Working Distance |
240mm |
|
Magnification for Main Microscope |
4×～21×zoom magnification |
|
Diameter of Field |
9.5mm～50mm |
|
Diopter Adjustment |
±7D |
|
Pupil Distance |
50mm～80mm |
|
Maximal Resolution |
112 LP/mm |
|
Illumination Source |
15V/150W, cold reflection medical halogen bulb |
|
Illumination Type |
6°coaxial illumination |
|
Coaxial Illumination |
≥35000lx |
|
Reaching Radius of Arm |
1210mm |
|
Adjusting Vertical Range |
760mm～1360mm |
|
Fine Focusing Range |
10mm |
|
Input Voltage |
AC220V±22V/50Hz±1Hz、AC110V±11V/60Hz±1Hz |
|
Power |
170VA |
|
Fuse |
AC250V T2.0A 、AC125V T4.0A |
|
Electrical Safety Standard |
Executive Standard GB9706.1-2007 Class Ⅰ |
|
Packing Volumn |
0.24m3，1 carton |
|
Total Weight |
48kg |
|
