CE Certificated, FDA registered

Features:
1.Sensitive big 7" touch LCD screen.
You just touch the screen to finish the measurement, the operation is easier and more convenient.
2.Measurement menu with recognizable icons.
it displays  a user-friendly graphical interface for an immediate understanding
3.Progressive measurement.
A graph helps the operator to improve the accuracy and speed in the measurement of near and far vision.
4.Automatic recongnition of single and progressive lens
5.Hi-speed UV measurement
just hold the lens through the sensor, the display will easily indicate the UV measurement by the progress bar
6.Built-in thermal printer
Quick data print with built-in printer,easy to reload printing paper.
7.Quick and clean dot marking.

Specifications:
  Measure scope
Sphere                0~±25D   0.01/0.12/0.25D steps
Cylinder              0~±9.99D  0.01/0.12/0.25D  steps
Axis                     0°~180°  (1°step)
ADD                    0~+9.99D   0.01/0.12/0.25D steps
prism                   0~15△    0.01/0.12/0.25△ steps
  mode
cylinder                +,+/-,-
prism                    X-Y,P-B
Contact lens         Soft/hard
Measuring mode: Single/progressive/ automatic recognition
  Others
Diameter of lens   ￠20~108mm
PD：                     45~90mm, 0.25mm steps
Speed                   0.1S
ABBE                    30~60
Display                 TFT LCD （7" bigger screen）
Printer                   Thermal print
Dimensions          300(D)*216(W)*456(H)mm
Weight                 ~6KG(NET)
Power supply      100~220V 50/60HZ
